Danfoss VLT AutomationDrive FC 360 Programming Guide

Table 27: Description of Warning Word (continued)
Bit Hex Dec Warning word Warning word 2 Warning word 3
Parameter 16-92 Warning
Word
Parameter 16-93 Warning
Word 2
Parameter 16-98 Warning
Word 3
29 20000000 536870912 Output freq. lim. (W62) BackEMF too high –
30 40000000 1073741824 Safe stop (W68) – –
31 80000000 2147483648 – – –
Table 28: Description of Extended Status Word
Bit Hex Dec Ext. status word Ext. status word 2 Ext. status word 3
Parameter 16-94 Ext. Status
Word
Parameter 16-95 Ext. Status
Word 2
Parameter 16-99 Ext. Status
Word 3
Extended Status Word
0 00000001 1 Ramping Off –
1 00000002 2 AMA running Hand/auto –
2 00000004 4 Start CW/CCW
start_possible is active, when
the DI selections [12] OR [13]
are active and the requested
direction matches the refer-
ence sign
Profibus OFF1 active –
3 00000008 8 Slow down
slow down command active,
for example via CTW bit 11 or
DI
Profibus OFF2 active –
4 00000010 16 Catch up
catch up command active, for
example via CTW bit 12 or DI
Profibus OFF3 active –
5 00000020 32 Feedback high
feedback > parameter 4-57
Warning Feedback High
– –
6 00000040 64 Feedback
low feedback < parameter
4-56 Warning Feedback Low
– –
7 00000080 128 Output current high
current > parameter 4-51
Warning Current High
Control ready –
8 00000100 256 Output current low
current < parameter 4-50
Warning Current Low
Drive ready –
312 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
