Programming Guide | VLT® AutomationDrive FC 360

Table 28: Description of Extended Status Word (continued)

Bit Hex Dec Ext. status word Ext. status word 2 Ext. status word 3

Parameter 16-94 Ext. Status

Word

Parameter 16-95 Ext. Status

Word 2

Parameter 16-99 Ext. Status

Word 3

9 00000200 512 Output freq high

speed > parameter 4-53

Warning Speed High

Quick stop –

10 00000400 1024 Output freq low

speed < parameter 4-52

Warning Speed Low

DC brake –

11 00000800 2048 Brake check OK

brake test NOT OK

Stop –

12 00001000 4096 Braking max.

BrakePower > Brakepower-

limit (2-12)

Latched –

13 00002000 8192 Braking Freeze output request –

14 00004000 16384 – Freeze output –

15 00008000 32768 OVC active Jog request –

16 00010000 65536 AC brake Jog –

17 00020000 131072 – Start request –

18 00040000 262144 – Start –

19 00080000 524288 Reference high

reference > parameter 4-55

Warning Reference High

– –

20 00100000 1048576 Reference low

reference < parameter 4-54

Warning Reference Low

Start delay –

21 00200000 2097152 Local reference

reference site = REMOTE ->

auto on pressed & active

Sleep –

22 00400000 4194304 – Sleep boost –

23 00800000 8388608 – Running/pipe filling –

24 01000000 16777216 – Drive bypass –

25 02000000 33554432 – – –

26 04000000 67108864 – External interlock –

27 08000000 134217728 – – –

28 10000000 268435456 Power Unit Off FlyStart active –

29 20000000 536870912 24 V Backup Plugged in – –
