D • Front Panel Control
Doc. 065051-03 1/08 307
b. Press Select Δ or Select ∇ to select YES (bypass the door lock) and press
Enter. The door lock will be disabled for 15 minutes. You can now
perform the alignment with the door open. To extend the bypass for
another 15 minutes, select
YES and press Enter again.
3. Press
Menu and 6 to go to the INJECT PORT ALIGNMENT screen.
4. Record the current values in the
X, Y, and Z ADDRESS fields.
X ____________
Y ____________
Z ____________
5. Verify that the cursor is in the
X ADDRESS field and press Enter.
The needle arm moves to the inject port.
6. Move the cursor to the
Z ADDRESS field and enter 180. Press Enter.
The needle moves down 180 steps. Note: Each step is 0.127 mm (0.005 in).
Be aware of unexpected sampling arm movement when operating with
the door open.
Soyez conscient de la possibilité de mouvements imprévus du bras
d'échantillon lorsqu'il est utilisé avec la porte ouverte.
Achten Sie beim Betrieb mit geöffneter Tür auf unerwartete
Bewegungen des Probenarms.
Figure D-16. Inject Port Alignment Screen
Help Prompt
INJECT PORT ALIGNMENT
X ADDRESS: 1340
1930
230
Y ADDRESS:
Z ADDRESS:
