AS Autosampler Operator’s Manual
312 Doc. 065051-03 1/08
NOTE This procedure has numerous steps. To help maintain
your place in the procedure, check off each step after
completing it.
1. Disconnect the needle seal line fitting from port S (5) of the injection valve.
For sequential mode, disconnect the diverter valve line fitting from port S (5)
on each injection valve. For simultaneous mode, disconnect the needle seal
line fitting from the Y-connector.
2. Press
Menu, 8, and 5 to go to the LIQUID CONTROL screen.
3. Select
VIAL#: INJ and press Enter.
The needle arm moves to the inject port.
NOTE Throughout the procedure, retain the current or default
settings for parameters, unless instructed otherwise.
4. Select the following options:
from FLUSH
SYRINGE SPEED: 5
SYRINGE
: SAMPLE
ACTION
: FILL
5. Press Enter.
NOTE To initiate a selected action, the cursor must be in the
ACTION field when you press Enter.
6. Select ACTION: EMPTY and press Enter.
Figure D-19. Liquid Control Screen
Help Prompt
LIQUID CONTROL
from
VIAL#:
ASPIRATE:
SYRINGE:
ACTION:
DISPENSE:
1
100
100
SAMPLE
ASPIRATE
uL
uL
NEEDLE
LOAD
46
NEEDLE HEIGHT:
SYRINGE SPEED:
4
INJ VALVE:
