3 • Operation and Maintenance
Doc. 065051-03 1/08 69
Table 3-9 also lists the maximum injection volume that can be specified in
the Chromeleon or Chromeleon Xpress sequence or in the front panel
schedule.
Notes
• To minimize the backpressure applied to the sample syringe pump,
use the largest ID tubing possible to make the injection loop.
• If a 1.5 mL vial is used, the maximum loop size is 500 μL and the
maximum injection volume is 1100
μL, regardless of the syringe size.
• For syringes that are 1,000 μL or smaller, the maximum loop size and
injection volume requires the syringe to aspirate from the sample vial
multiple times. This can result in reduced precision. For maximum
precision, use a loop size and injection volume that require only a
single sample aspiration.
Sample
Syringe
Sampling
Needle Assembly
Maximum Sample
Loop Size
Maximum
Injection Volume
≤1,000 μL1.2mL 500μL
a
a. Requires a 1.5 mL vial or a 2 mL deep well plate.
1,100 μL
5mL 8.5mL 4,000μL
b
b. Requires a 10 mL vial.
4,700 μL
10 mL 8.5 mL 7,000 μL
b
8,000 μL
Table 3-9. Maximum Sample Loop Sizes and Injection Volumes
