FLIR D3300 Series - 22 System Specifications; System; InputsOutputs; Display

System Specifications
22
22.1 System
Operating System
Embedded LINUX
Pentaplex
Simultaneous View, Record, Playback, Backup &
Remote Monitoring
Number of Channels 4 / 8 / 12 / 16 / 32–Channel
System Navigation USB Mouse, IR Remote Controller
User Authority By user group
22.2 Inputs/Outputs
Video IN D3304: 4 x 1Vp-p, CVBS, 75ohms, BNC
D3308: 8 x 1Vp-p, CVBS, 75ohms, BNC
D3212: 12 x 1Vp-p, CVBS, 75ohms, BNC
D3216: 16 x 1Vp-p, CVBS, 75ohms, BNC
D3316: 16 x 1Vp-p, CVBS, 75ohms, BNC
D3332: 32 x 1Vp-p, CVBS, 75ohms, BNC
Video Outputs 1 x HDMI, 1 x VGA, 1 x BNC (D3304 / D3308 /
D3312 / D3216) / 2 x BNC (D3316 / D3332)
Loop Output D3304: 4CH, D3308: 8CH, D3312: 12CH, D3216:
16CH, D3316: 16CH,
D3332: 16CH
Audio IN
D3304: 4CH BNC, D3308: 8CH BNC, D3312: 2CH
BNC, D3216: 4CH BNC,
D3316: 16CH BNC, D3332: 16CH BNC
Audio OUT D3304: 1CH BNC, D3308: 1CH BNC, D3312: 1CH
BNC, D3216: 1CH BNC,
D3316: 2CH BNC, D3332: 2BNC
USB Port 2x USB, USB 2.0
Alarm IN
D3304: 4CH, D3308: 8CH, D3312: 8CH, D3216:
8CH, D3316: 16CH
D3332: 16CH
Alarm OUT D3304 / D3308 / D3312 / D3216 / D3316: 1CH,
D3332: 4CH
PTZ Control RS-485 Pelco D & P Protocol
22.3 Display
Video Output Resolution
800x600, 1024x768, 1280x1024, 1440x900,
1920x1080
Live Display D3304: 1, 4
D3308: 1, 4, 9
D3312: 1, 4, 9, 12
D3216/D3316: 1, 4, 9, 16
D3332: 1, 4, 9, 16, 25, 32
