Basic Setup
6
6.1 Step 1: Connect the BNC Cameras
• Connect BNC cameras to the Video Input ports on the rear panel of the DVR.
8–channel model shown
6.2 Step 2: Connect the Mouse
• Connect a USB mouse (included) to one of the USB ports.
8–channel model shown
6.3 Step 3: Connect the Ethernet Cable
• Connect an Ethernet cable (not included) to the LAN port on the rear panel of the DVR.
Connect the other end of the Ethernet cable to a router on your network.
8–channel model shown
6.4 Step 4: Connect the Monitor
• Connect an HDMI cable (not included) from the HDMI port to the TV or monitor
(recommended).
• Connect a VGA cable (not included) from the VGA port to the monitor.
#LX400005; r. 1.0/13714/13883; en-US
