Replacing the Hard Drive26
4. Connect the power and data cables.
5. Replace the DVR cover.
26.3 Installing Hard Drives (D3332)
CAUTION
Make sure that the power cable has been disconnected before changing the hard drive.
Steps to service the hard drives on D3332 depend if you are installing or removing hard
drives 1~4 or 5~8.
Step 1 of 3: Remove the DVR cover:
1. Remove the rear panel screws (2x).
Note
You do not need to remove the side panel screws.
2. Slide the top panel back about 1/2" and then lift it off of the DVR.
#LX400005; r. 1.0/13714/13883; en-US
176
