FLIR D3300 Series User Manual

Front Panel4
5. PTZ /
:
• Within system menus: Press to confirm a selection.
• To open the System Information window: In Live Viewing mode, press once.
• To open PTZ Controls: In Live Viewing Mode, press once and release then press
and hold.
6. USB Port: Connect a USB mouse (included) or USB flash drive (not included) for data
backup or firmware updates.
4.2 D3332 (32-Channel)
1
2
3
4
5
6
7
8 10
9
1. LED Indicators:
• PWR: Power LED.
• HDD: Hard disk activity LED.
2. IR Sensor: IR receiver for the remote control.
3. Ch1 ~ Ch0: Press to view channel in Full-screen View. To access channels 10 and
greater: Press 0 for channel 10 or 1+0 for channel 10, 1+1 for channel 11, 1+2 for
channel 12, etc.
4. CH-/CH+: Press to select previous/next channel.
5.
: Press to open split-screen view. Press multiple times to select split-screen mode.
6.
: Press to start/stop Sequence Mode.
#LX400005; r. 1.0/13714/13883; en-US
7
