Front Panel4
7. Menu & Playback Controls:
•
: In Playback Mode, press to rewind. Press repeatedly to increase rewind speed.
•
: In Playback Mode, press to play / pause video.
• In Viewing mode, press to open Search Menu to select playback time.
•
: In Playback Mode, press to fast forward. Press repeatedly to increase fast for-
ward speed.
•
: In Playback Mode, press to stop video playback.
• In Live Viewing Mode, press to stop DVR recording. Password required; does
not override scheduled recording.
•
: Press to stop / resume recording. When the channel displays a red box with
the letter "C", the channel is recording.
• Menu / Esc: Opens the system menu. In menus, press to go back / exit menus.
8. Navigation Buttons:
• ▲: Press to move cursor up.
• ▼: Press to move cursor down.
• ◀: Press to move cursor left.
• ▶: Press to move cursor right.
9. PTZ /
:
• Within system menus: Press to confirm a selection.
• To open the System Information window: In Live Viewing mode, press once.
• To open PTZ Controls: In Live Viewing Mode, press once and release then press
and hold.
• USB Port: Connect a USB mouse (included) or USB flash drive (not included) for
data backup or firmware updates.
#LX400005; r. 1.0/13714/13883; en-US
8
