Replacing the Hard Drive
26
The system comes with a pre-installed SATA hard drive. You can expand the hard drive ca-
pacity with a maximum of two 2TB 3.5" or 2.5" SATA hard drives.
Note
The D3332 supports up to eight 4TB 3.5 SATA hard drives (for a maximum storage capacity of 32TB).
For D3332, you must use hard drives rated for 7200RPM or higher. Different steps are required to install
hard drives on the D3332. For details, see 26.2 Installing the Hard Drive, page 174.
26.1 Removing the Hard Drive
CAUTION
Make sure that the power cable has been disconnected before changing the hard drive.
1. Remove the screws from each side panel (x2) and rear panel (x4) of the cover.
2. Gently slide the cover away from the rear panel and lift off. Be careful of sharp edges.
3. Disconnect the power and data cables.
#LX400005; r. 1.0/13714/13883; en-US
173
