FLIR D3300 Series User Manual

Replacing the Hard Drive26
4. Next remove the hard drive from the housing:
• If your system has a 3.5" hard drive, remove the 4 screws holding the hard drive
bracket and remove the bracket from the DVR. Remove the 4 screws securing the
hard drive to the bracket and remove the hard drive from the bracket. Replace the
hard drive bracket and hard drive bracket screws.
• If your system has a 2.5" hard drive, turn the DVR over carefully. Hold the hard drive
in place and remove the 4 screws securing the hard drive. Keep holding the hard
drive and turn the DVR back over. Remove the hard drive from the DVR.
CAUTION
Make sure to hold the hard drive in place
while removing the hard drive screws and
turning the DVR to avoid damaging the DVR.
5. Replace the DVR cover.
26.2 Installing the Hard Drive
CAUTION
Make sure that the power cable has been disconnected before changing the hard drive.
1. Remove the screws from each side panel (x2) and rear panel (x4) of the cover.
2. Gently slide the cover away from the rear panel and lift off. Be careful of sharp edges.
#LX400005; r. 1.0/13714/13883; en-US
174
