Connecting a PTZ Camera
23
3. Configure the following according to your PTZ camera’s specifications:
• Channel: Select the channel the PTZ camera is connected to.
• Protocol: Select from Pelco-D or Pelco-P.
• Baud rate: Select the PTZ camera’s baud rate.
• Data Bit: Select from 5~8 data bits.
• Stop Bit: Select from 1 or 2 stop bits.
• Parity: Select from None, Odd, Even, Mark or Space.
• Cruise: Select Enable to enable PTZ cruise.
• Address: Enter the PTZ camera’s address
Use the Copy To drop-down menu to copy the PTZ settings to multiple channels.
4. Click Apply to save your settings.
23.2 Using the PTZ Menu (Local DVR)
To control the PTZ camera locally on your DVR:
1. Select the channel that the PTZ camera is connected to.
2. Press the PTZ /
button once and release then press and hold. Enter the system
password. The PTZ menu opens.
3. Use the on-screen PTZ controls to control the camera.
#LX400005; r. 1.0/13714/13883; en-US
165
