Replacing the Hard Drive26
Step 2A of 3: Install hard drives 5~8:
1. Remove the screw at the top of the center beam.
2. Lift the back of the top HDD plate and pull it up to remove it from the DVR.
3. Place the HDD(s) under the bottom HDD plate upside down with the power and data
connectors facing the rear of the DVR. Insert 4x hard drive screws per HDD.
#LX400005; r. 1.0/13714/13883; en-US
177
