Using the On-Screen Display
9
To use Picture in Picture Mode:
1. Right-click to open the Menu Bar and select the PIP1X1 button (
) or PIP1X2 button
(
). PIP1X1 shows 1 channel in full screen and 1 other channel; PIP1X2 shows 1
channel in full screen and 2 other channels.
• Picture in Picture Mode opens.
• To change the full-screen channel, click anywhere in the main viewing area.
• To change the smaller channels, click inside the channel.
• To move the smaller channels around the screen, click inside the white bar and
drag.
• Right-click to exit and return to Live Viewing Mode.
#LX400005; r. 1.0/13714/13883; en-US
