Remote Viewing Interface
16
To configure a privacy zone:
1. Click the Remote Setting tab, and then click Display > Privacy Zone.
2. In the Channel drop-down menu, select the channel you wish to configure.
3. Select the Privacy Zone checkbox to enable privacy masking.
4. Drag your mouse cursor over the areas you wish to black out. A red box indicates the
area that is masked (blocked out).
• To remove a privacy area, click on the red box, then click the Delete button.
5. Click Save to apply your settings.
#LX400005; r. 1.0/13714/13883; en-US
84
