7.6 Replacing the SAS / SATA HDD / SSD
backplane
7.6.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Suspending BitLocker functionality" on page 59
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê Remove all HDD / SSD modules from the server as described in section
"Removing 2.5-inch HDD / SSD / PCIe SSD modules" on page 112.
V CAUTION!
Ensure that all hard disk drives are uniquely identified so that you can
reinsert them into their original bays after replacing the HDD
backplane.
Ê "Getting access to the component" on page 48
Ê "Removing memory boards" on page 220
Ê "Removing the memory rug" on page 301
Ê "Unlock the optical drive" on page 264
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Philips PH2 / (+) No. 2 screw driver
