13.2.1.3 Installing the Chassis ID
Figure 168: Installing the Chassis ID
Ê Insert the Chassis ID and fix it with the screw (1).
Ê Reconnect the cable to the Chassis ID (2).
13.2.1.4 Concluding steps
Ê "Installing the fan box" on page 131
Ê "Installing memory boards" on page 223
Ê "Reassembling" on page 53
Ê "Connecting the server to the power source" on page 57
Ê "Switching on the server" on page 58
Ê "Verifying system information backup / restore" on page 69
Ê Store your server’s system information on the Chassis ID EPROM
integrated into the front panel board. For further information on how to obtain
and use the ChassisId_Prom Tool, refer to section "Using the Chassis ID
Prom Tool" on page 83.
Ê "Enabling SVOM boot watchdog functionality" on page 74
Ê "Resuming BitLocker functionality" on page 80
