16.3.2 Connectors and indicators on the rear side
16.3.2.1 Rear side connectors
Figure 198: Rear side connectors
I The serial connector COM1 can be used as default interface or to
communicate with the iRMC S4.
1 Serial connector COM1
(turquoise)
4 Management LAN connector
2 2x Fibre glass connectors 5 2x USB connectors (black)
3 Video connector (blue) 6 Standard LAN connectors
(upper: LAN 2, lower: LAN 1)
