Fujitsu Primergy RX4770 M1 - Basic Information

202 Upgrade and Maintenance Manual RX4770 M1
Main memory
10.1 Basic information
The server can be equipped with up to 8 memory boards, each of which can
accommodate up to 12 memory modules (DIMMs). The memory board
numbering is shown in the following figure:
Figure 100: Memory board numbering
#4
#3
#2
#1
#5
#6
#7
#8
