268
Upgrade and Mai
ntenance Manual
RX4770
M1
Front panel and Chassis ID
Ê
"Removing memory boards" on page
220
Ê
"Removing the fan box" on page
127
13.1.1.2
Removing t
he front panel module
Figure 165: Removing the f
ront panel
Ê
Disconnect the front panel cable from the fan board (see oval).
Ê
Press on the plastic tabs (1) on both sides of the front
panel and push it
outward (2).
267
