RX4770 M1 Upgrade and Maintenance Manual 267
13 Front panel and Chassis ID
Safety notes
V CAUTION!
● When inserting the front panel module into the server, ensure not to
pinch or strain any connected cables.
● Circuit boards and soldered parts of internal options are exposed and
can be damaged by static electricity. Always discharge static build-up
(e.g. by touching a grounded object) before handling electrostatic-
sensitive devices (ESDs)
● Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
● For further information, please refer to chapter "Important
information" on page 31.
13.1 Front panel module
13.1.1 Replacing the front panel module
13.1.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 59
Ê "Disabling SVOM boot watchdog functionality" on page 60
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê "Getting access to the component" on page 48
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Philips PH2 / (+) No. 2 screw driver
