220
Upgrade and Mai
ntenance Manual
RX4770
M1
Main memory
10.2.2
Removing memory boards
Buttons an
d indictors on
the me
mory board
Each memory board comes with the foll
owing sticker showing additional
information:
I
The Hot Swap functionality is not yet releas
ed.
Figure 122: Buttons and indicators on the memory board
1
12x DIMM fault LED
4
Attention LED
2
Mirror ready LED
5
Attention button
3
Power LED
219
