278 Upgrade and Maintenance Manual RX4770 M1
System board and components
14.3.2.2 Installation the UFM
Figure 171: UFM kit
Ê Unscrew the UFM nylon screw and remove the UFM spacer.
1 USB Flash Module (UFM) 2 UFM spacer (not used)
3 UFM nylon screw
