RX4770 M1 Upgrade and Maintenance Manual 27
Before you start
2.3 Tools you need at hand
When preparing the maintenance task, ensure that all required tools are
available according to the overview below. You will find a list of required tools at
the beginning of each procedure.
Screw driver /
Bit insert /
torque
Screw Usage Type
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5 / PZ2
0.6 Nm
Slot bracket
to controller
board
M3 x 4.5 mm
(silver)
C26192-Y10-C67
Phillips
PH2 / (+) No. 2
0.49 Nm
System
board, fan
box, fan
backplane
#6-32 (6 mm)
(silver)
Phillips
PH0 / (+) No. 0
0.4 Nm
2.5-inch
HDD/SSDs
M3 x 3.5 mm
Wafer head screw
(silver)
C26192-Y10-
C102
TPM bit insert
Dedicated TPM
screw driver /
TPM module
fixing tool (for the
Japanese market)
0.4 Nm
TPM screw
One way
head
(black)
REM 3 x 15 mm
(black)
C26192-Y10-
C176
Phillips
PH0 / (+) No. 0
0.06 Nm
UFM nylon
screw
M3 x 4.5 mm
(white)
A3C40109082
Table 2: List of required tools and used screws
