Fujitsu Primergy RX4770 M1 User Manual

28 Upgrade and Maintenance Manual RX4770 M1
Before you start
Phillips
PH2 / (+) No. 2
0.6 Nm
USB 3.0 PCI
card D3305
M3 x 5 mm
(silver)
(contained in card
kit S26361-D3305-
A10)
Phillips
PH1 / (+) No. 1
0.4 Nm
TFM M2.5 x 4 mm
Phillips
PH2 / (+) No. 2
0.6 Nm
housing
cover
countersunk
M3 x 5 mm
(silver)
Phillips
PH2 / (+) No. 2
0.49 Nm
front bezel
(black)
#6-32 (7.9 mm)
Screw driver /
Bit insert /
torque
Screw Usage Type
Table 2: List of required tools and used screws
