RX4770 M1 Upgrade and Maintenance Manual 277
System board and components
14.3 USB Flash Module (UFM)
14.3.1 Basic Information
I In this server the UFM is located on the BMC riser.
14.3.2 Installing the UFM
14.3.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 59
Ê "Disabling SVOM boot watchdog functionality" on page 60
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê "Getting access to the component" on page 48
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH0 / (+) No. 0 screw driver
Phillips PH2 / (+) No. 2 screw driver
