RX4770 M1 Upgrade and Maintenance Manual 177
Expansion cards and backup units
9.8.2 Installing an FBU
V CAUTION!
For further safety information, please refer to chapter "Important
information" on page 31.
9.8.2.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 60
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê "Getting access to the component" on page 48
Ê "Removing memory boards" on page 220
Ê "Removing the memory rug" on page 301
9.8.2.2 Installing a TFM to the SAS riser (if applicable)
I To connect an FBU to the controller D3116 or D3216 you need a TFM.
Other controllers so as D9285 can be connected directly.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Phillips PH2 / (+) No. 2 screw driver
