316 Upgrade and Maintenance Manual RX4770 M1
Appendix
16.1.2 Server rear
Figure 194: PRIMERGY RX4770 M1 rear
Pos. Component
1 SAS riser slot
2
Rear connectors, button & indicators (see "Connectors and indicators
on the rear side" on page 323)
3 Optional expansion card slots
4 Power supply unit slots
