9.4.1.2 Removing the SAS riser
Figure 52: Removing the SAS riser
Ê Remove the DVD cable (1).
Ê Remove the SAS cables for channels "0 - 3" (2) and "4 - 7" (3).
Ê Open the slot lock (4).
Ê Carefully pull up on the SAS riser in a vertical motion and remove it from its
slot (5).
9.4.1.3 Concluding steps
Ê "Reassembling" on page 53
Ê "Connecting the server to the power source" on page 57
Ê "Switching on the server" on page 58
Ê In order to configure an expansion card that has been installed or replaced,
the card’s Option ROM has to be enabled in the system board BIOS. If
applicable, proceed as described in section "Enabling Option ROM scan" on
page 71.
Ê "Enabling SVOM boot watchdog functionality" on page 74
Ê "Resuming BitLocker functionality" on page 80
Ê "Updating RAID controller firmware" on page 70
