RX4770 M1 Upgrade and Maintenance Manual 191
Expansion cards and backup units
9.8.4.3 Removing the FBU from the holder
Figure 90: Removing the FBU from the holder
Ê Pull the FBU at a slight angle out of the holder.
9.8.4.4 Installing a new FBU
Ê "Connecting the FBU cable to the FBU" on page 182
Ê "Preparing the FBU" on page 181
Ê "Installing the FBU holder onto the chassis" on page 183
9.8.4.5 Concluding steps
Ê "Installing the memory rug" on page 307
Ê "Installing memory boards" on page 223
Ê "Reassembling" on page 53
Ê "Connecting the server to the power source" on page 57
Ê "Switching on the server" on page 58
A message indicates that the recalibration of the FBU starts automatically
and will be finished within a few minutes.
Ê If applicable, "Updating RAID controller firmware" on page 70.
Ê "Enabling SVOM boot watchdog functionality" on page 74
