9.9 Handling SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the Ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
9.9.1 Installing SFP+ transceiver modules
Preparing the SFP+ transceiver module
Figure 91: Removing the protective optical port plug
Ê Remove the SFP+ transceiver module from its protective packaging.
Ê Remove the optical port plug from the new / additional SFP+ transceiver
module.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: Phillips PH2 / (+) No. 2 screw driver
