RX4770 M1 Upgrade and Maintenance Manual 157
Expansion cards and backup units
9.5.2 Upgrading the BMC riser
9.5.2.1 Basic information
The BMC riser can be upgraded with an add-on card (the LAN Mezzanine card).
The following figure shows the parts of the LAN Mezzanine card:
Figure 56: All parts of the LAN Mezzanine card
9.5.2.2 Preliminary steps
Ê "Suspending BitLocker functionality" on page 59
Ê "Disabling SVOM boot watchdog functionality" on page 60
Ê "Shutting down the server" on page 46
1 Required screws
2 Cable
3 LAN Mezzanine card
4 Punched plate
5 Adapter card
