4.5 Reassembling
4.5.1 Closing the server
V CAUTION!
● Before attaching the covers, make sure no unnecessary parts or tools
are left inside the server.
● In order to comply with applicable EMC regulations (regulations on
electromagnetic compatibility) and satisfy cooling requirements, the
PRIMERGY RX4770 M1 server must not run while the housing cover
is removed.
● For further safety information, please refer to chapter "Important
information" on page 31.
4.5.1.1 Mounting the housing cover
Figure 6: Mounting the housing cover
Ê Place the housing cover onto the server such that it projects approximately
2 cm at the back (see circle in figure above).
Ê Push the housing cover in the direction of the arrow until it engages.
Ê Fasten the little screw on the cover (see figure 5 on page 52).
