Fujitsu Primergy RX4770 M1 - Removing the Slot Bracket; Installing an Expansion Card

RX4770 M1 Upgrade and Maintenance Manual 143
Expansion cards and backup units
9.3.1.2 Removing the slot bracket
Figure 48: Removing the slot bracket
Ê Open the slot lock (1).
Ê Remove the slot bracket (2).
V CAUTION!
Keep the slot bracket for further use.
Always replace slot brackets into unused PCI slot openings to comply
with applicable EMC regulations and satisfy cooling requirements.
9.3.1.3 Installing an expansion card
Ê Remove the expansion card from its protective packaging.
I For further instructions regarding controller settings, please refer to
the accompanying documentation.
