330 Upgrade and Maintenance Manual RX4770 M1
Appendix
16.4 Onboard settings
Figure 205: Onboard settings on system board D3342
Figure 206: Settings of the switches on system board D3342
CPU 1
CPU 2
BIOS
TPM
Slot 4 PCIe x16 (x16)
Slot 3 PCIe x8 (x8)
Slot 2 PCIe x8 (x8)
Slot 1 PCIe x8 (x8)
BMC - Riser
LAN -Controller
SAS-Riser (Slot 11)
SATA 1
SATA 2
Battery
USB 2/3/4
ID Button
Sw. 4
Sw. 6
Sw. 8
Sw. 7
Sw.13
System Board
D3342
Settings
Enabled Disabled
SW131
BIOS Recovery Mode
Switch # Description
SW82
Password clear
SW63
Password skip
SW44
1=OFF 1=ON
2=ON 2=OFF
BIOS Write Protect
(Force Write Protect)
1=ON 1=OFF
4=ON 4=OFF
4=ON 4=OFF
1
ON
1
ON
1
ON
1
ON
1
ON
1
ON
1
ON
1
ON
(=Default)
