182 Upgrade and Maintenance Manual RX4770 M1
Expansion cards and backup units
9.8.2.4 Connecting the FBU cable to the FBU
Figure 79: Connecting the FBU adapter cable to the FBU
Ê Connect the cable end on the FBU module to the FBU adapter cable as
shown.
