Fujitsu Primergy RX4770 M1 - Trusted Platform Module (TPM)

288 Upgrade and Maintenance Manual RX4770 M1
System board and components
14.4 Trusted Platform Module (TPM)
14.4.1 Installing the TPM
14.4.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 59
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê "Getting access to the component" on page 48
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Philips PH2 / (+) No. 2 screw driver
Installing the TPM:
– Bit screw driver
–TPM bit insert
(
*
)
(
*
)
For the Japanese market:
– TPM module fixing tool (S26361-F3552-L909)
