RX4770 M1 Upgrade and Maintenance Manual 317
Appendix
16.1.3 Server interior
Figure 195: PRIMERGY RX4770 M1 interior
Pos. Component
1BMC riser
2 SAS riser
3 PCIe slots
4 Battery
5TPM
6 Processor / CPU heat sink
7 Memory boards
8 Fans
