RX4770 M1 Upgrade and Maintenance Manual 311
15 Cables
Safety notes
V CAUTION!
● Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
● Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
● Immediately replace cables with damaged shielding.
● Always use shielded network cables.
15.1 List of used cables
# Description Routing Qty. P/N
1 OP Board cable OP to Fan Backplane 1 A3C40113995
2 Chassis ID/ Temp cable Chassis ID to Fan Backplane 1 A3C40113993
3 Power cable 1 Pwr-Dist.-Board to System board 4 A3C40175017
4 Power cable 2 Pwr-Dist.-Board to System board 1 A3C40175018
5 Power cable 3 Pwr-Dist.-Board to System board 1 A3C40175019
6 FAN board cable 1 Fan Backplane to System Board 1 A3C40175020
7 FAN board cable 2 Fan Backplane to System Board 1 A3C40175020
8 USB cable Fan Backplane to System Board 1 A3C40175021
9 PDB sideband cable Pwr-Dist.-Board to System board 1 A3C40175042
10 HDD SMBus cable HDD Backplane to System Board 1 A3C40175043
11 RMII cable on BMC Riser 1 A3C40175044
12 HDD board power
cable
Pwr-Dist.-Board to HDD Backplane 1 A3C40175045
13 FAN board power cable Pwr-Dist.-Board to Fan Backplane 1 A3C40175046
14 LSD cable LSD to System Board 1 A3C40175067
15 DVD cable HDD Backplane to System Board 1 A3C40175047
Table 5: List of used cables
