Fujitsu Primergy RX4770 M1 User Manual

312 Upgrade and Maintenance Manual RX4770 M1
Cables
16 SAS cable 1
(D2607, D3116)
HDD Backplane to System Board Opt. A3C40175048
17 SAS cable 2
(D2607, D3116)
HDD Backplane to System Board Opt. A3C40175049
18 D3216 SAS cable 1 HDD Backplane to System Board Opt. A3C40169671
/ T26139-
Y4040-V9
19 D3216 SAS cable 2 HDD Backplane to System Board Opt. A3C40169673
/ T26139-
Y4040-V10
20 FBU Cable (D3116) FBU to SAS Riser Opt. T26139-
Y4032-V1
21 FBU Cable (D3216) FBU to SAS Riser Opt. T26139-
Y4031-V103
22 PCIe SSD cable 1 HDD Backplane to PCIe SW Card Opt. A3C40175052
23 PCIe SSD cable 2 HDD Backplane to PCIe SW Card Opt. A3C40175053
24 PCIe SSD cable 3 HDD Backplane to PCIe SW Card Opt. A3C40175054
25 PCIe SSD cable 4 HDD Backplane to PCIe SW Card Opt. A3C40175055
# Description Routing Qty. P/N
Table 5: List of used cables
