RX4770 M1 Upgrade and Maintenance Manual 283
System board and components
14.3.4 Replacing the UFM
14.3.4.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 59
Ê "Disabling SVOM boot watchdog functionality" on page 60
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting power cords" on page 46
Ê "Getting access to the component" on page 48
14.3.4.2 Removing the UFM
Ê "Removing the UFM" on page 281
Ê The UFM spacer remains on the BMC riser.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Philips PH0 / (+) No. 0 screw driver
– combination pliers and flat nose pliers
