RX4770 M1 Upgrade and Maintenance Manual 289
System board and components
14.4.1.2 Installing the TPM
Figure 178: TPM kit
Figure 179: TPM mounting location
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The white TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
1 Cut-out for TPM spacer 2 TPM connector
