RX4770 M1 Upgrade and Maintenance Manual 135
Expansion cards and backup units
PCI Slot No. Slot Connected to
Length Link
SAS riser Slot (#11)
(for Modular RAID)
1/2 Gen3 x8 CPU1
LAN Ctrl. Slot 1/2 Gen3 x8 (x2)
#1 1/2 Gen3 x8
#2 1/2 Gen3 x8 CPU2
#3 1/2 Gen3 x8
#4 3/4 Gen3 x16
#5 1/2 Gen3 x8 CPU3
#6 1/2 Gen3 x8
#7 3/4 Gen3 x16
#8 1/2 Gen3 x8 CPU4
#9 1/2 Gen3 x8
#10 1/2 Gen3 x8
Table 4: PCIe slot configuration
