232 Upgrade and Maintenance Manual RX4770 M1
Processors
Removing the mid-brace
Figure 132: Removal of the mid-brace
Ê Remove the 3 screws (see arrows) and lift up the mid-brace out of the
housing.
Ê Remove the respective heat sink as described in section "Removing
processor heat sinks" on page 254.
