RX4770 M1 Upgrade and Maintenance Manual 285
System board and components
Figure 176: Installing the UFM
Ê Fit the new UFM on the UFM connector and the remaining UFM spacer (1).
Ê Secure the UFM to the UFM spacer with the nylon screw (2).
