RX4770 M1 Upgrade and Maintenance Manual 47
Basic hardware procedures
Figure 2: Removing the power cord from the PSU cable clamp
Ê Open on the locking lever on the PSU cable clamp (1).
Ê Disconnect the power cord from the PSU and remove it from the cable
tie (2).
