When using a lifter, this removal procedure needs to be carried out by
maintenance personnel.
V CAUTION!
Do not lift the server using the plastic handles.
Figure 4: Removing the server from the rack
Ê Release the locking bars on both rails (1).
Ê Lift up the front of the server as shown so that the front and middle rack
mounting bolts are disengaged from the mounting points on the telescopic
rails.
Ê Lift the server out of the rear mounting points (3) and place it on an even
surface.
