IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-121
PRELIMINARY
8-5-14-5 PSB Board Installation Procedure
1.) Fit the previously-removed components to the new PSB Board.
Refer to the following instructions:
2) Return the Front End door assembly to the system, reconnect the cables (previously disconnected),
close the cabinet cage door and fasten securely with the two latches:
3) Refit the following covers: front, DVD, right side, left side
4.) Turn ON power to the system.
• ECG/Respiratory Module Assembly Installation Procedure on page 8 - 108
• CFE Board Installation Procedure on page 8 - 115
• Front End Door Assembly Closing and Installation Procedure on page 8 - 87
• Front Cover Installation Procedure on page 8 - 19
• DVD Cover Installation Procedure on page 8 - 12
• Right Side Cover Installation Procedure on page 8 - 10
• Air Inlet (Left Side) Cover Installation Procedure on page 8 - 8
