224
────────────────────────────────────────────────────
11.4 Command Reference
────────────────────────────────────────────────────
■
Normal measurement print/save item setting
Synta
x
NORMal:DATAout:ITEM data1,data2
dat
a
data1, data2 0 to 255 (numerical data in NR 1)
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
data1
Instantan-
eou
power
Instantan-
eou
current
Instantan-
eou
voltage
data2
Minimum
power
Minimum
current
Minimum
voltage
Maximum
power
Maximum
current
Maximum
voltage
Functio
n
･ Sets the print/save items for normal measurement mode. Send data with
the bits corresponding to the items to be output set.
･ No error results if a bit with no corresponding item is set.
Erro
r
･ If the value other than setting limit is set, an execution error is generated.
･ In the following circumstances, a device dependent error generated:
In the event of a system error.
Exampl
e
Transmission
":NORM:DATA:ITEM 7,63"
Sets the normal measurement mode print/save items to "all data".
■ Normal measurement print/save item query
Synta
x
NORMal:DATAout:ITEM?
Functio
n
Returns the print/save items for normal measurement mode as a numerical
value (data1, data2) in NR1 format. This value is one of the set: 0 through
255.
Respons
e
synta
x
If headers are ON
If headers are OFF
":NORMAL:DATAOUT:ITEM data1,data2"
"data1,data2"
Exampl
e
If headers are ON
If headers are OFF
Transmission
Response
":NORM:DATA:ITEM?"
":NORMAL:DATAOUT:ITEM 7,0"
":NORM:DATA:ITEM?"
"7,0"
N
ORMal:DATAout:ITEM
N
ORMal:DATAout:ITEM?
